All movements are hydraulic

All the machine's movements are controlled by a high-efficiency motor pump unit (driven by an inverter), located in the oil tank and easily inspectable.

Special machine plans

The original design of the machine plates allows the assembly of the dies only, thus significantly reducing the size and cost of the moulds.

Movements

The press is governed by microprocessors that monitor and manage the movements, times and temperatures of the production cycle.

Proportional Hydraulics

Thanks to proportional hydraulics, the pressures during the cycle phases are managed and memorized by the machine.

Maximum security

CE certification.

Mold safety

Low pressure approach, with adjustable pressure threshold.

Color touch screen display

USB output and Ethernet connection (Modbus TCP) as standard or OPC-UA (Optional)

Cooling Management

The amount of coolant flow at various points in the press, including the mold, can be adjusted using a flow meter.
For mould temperatures up to 90°C, a specific temperature controller for Babyplast is available with the option of direct control (On/Off, temperatures, alarms) from the machine.

Heating the mold or hot chamber

For mold temperatures up to 200°C, the machine comes standard with two 230V heating zones. These allow you to control the mold temperature directly from the display by inserting cartridge heaters and thermocouples. These same zones can also be used to control a nozzle or hot runner.

Decentralized injection

The injection unit has two injection positions: one central and one 25 mm lower. In the case of a single impression, where central injection is not possible (for aesthetic reasons), the cavity can be kept central to the planes by injecting on one side.
