All movements are hydraulic

All the machine's movements are controlled by a high-efficiency motor pump unit located in the oil tank and easily inspected.

Pneumatic safety gate

Pneumatic drive for opening and closing the mould protection gate (Standard and “V” Table versions).

Standard machine plans

The machine's design allows for quick and easy assembly. In some cases, with minor modifications, existing molds can be used.

Movements

The press is governed by two microprocessors that monitor and manage the movements, times and temperatures of the production cycle.

Proportional Hydraulics

Thanks to proportional hydraulics, the pressures during the cycle phases are managed and stored by the machine.

Maximum security

CE certification.

Mold safety

Approaching in low pressure.

Color Touch Screen Display

USB output and Ethernet connection (Modbus TCP)

Cooling Management

The flow rate of the coolant at various points in the press, including the mold, can be adjusted using a flow meter. For mold temperatures up to 90°C, a specific Babyplast thermoregulator is available (only 0.7 kW).

Heating the mold or hot chamber

For mold temperatures up to 200°C, the machine has two 230V heating zones for the mold or hot runner. To condition the mold, you can insert cartridge heaters and control their heating in % or °C (using thermocouples), or you can use a nozzle or hot runner, managing their heating directly from the machine.

Injection possible in three different positions

The injection group, positioned horizontally, has three injection positions (45mm, 70mm and 95mm) with respect to the lower machine plane.
